$0.21000-4999 Piece/Pieces
$0.125000-9999 Piece/Pieces
$0.08≥10000Piece/Pieces
| Payment Type: | T/T |
| Incoterm: | FOB,EXW |
| Transportation: | Ocean |
| Port: | ShangHai,LianYunGang |
Brand: ShiJingChangTian
Material: Alloy Steel/Stainless Steel
Specification: M8-M30, Customization
| Selling Units | : | Piece/Pieces |
| Package Type | : | We will pack and ship according to customer's requirements |
The file is encrypted. Please fill in the following information to continue accessing it
| Size | Thread Size | Anchor Length (mm) | Diameter φ(mm) | Min Embedment (mm) | Max Fixture Thickness (mm) | Pull Out Load In Concrete (kgf)/(KN) |
| M8*80 | M8-P1.25 | 80 | 8 | 55 | 40 | 950 |
| M8*85 | M8-P1.25 | 85 | 8 | 55 | 45 | 950 |
| M8*90 | M8-P1.25 | 90 | 8 | 55 | 50 | 950 |
| M10*100 | M10-P1.5 | 100 | 10 | 70 | 40 | 1320 |
| M10*105 | M10-P1.5 | 105 | 10 | 70 | 45 | 1320 |
| M10*110 | M10-P1.5 | 110 | 10 | 70 | 50 | 1320 |
| M12*90 | M12-P1.75 | 90 | 12 | 80 | 20 | 1980 |
| M12*100 | M12-P1.75 | 100 | 12 | 80 | 30 | 1980 |
| M12*110 | M12-P1.75 | 110 | 12 | 80 | 40 | 1980 |
| M12*120 | M12-P1.75 | 120 | 12 | 80 | 50 | 1980 |
| M16*110 | M16-P2.0 | 110 | 16 | 100 | 20 | 2750 |
| M16*140 | M16-P2.0 | 140 | 16 | 110 | 50 | 2750 |
| M16*150 | M16-P2.0 | 150 | 16 | 110 | 60 | 2750 |
| M20*160 | M20-P2.5 | 160 | 20 | 150 | 40 | 4660 |
| M20*200 | M20-P2.5 | 200 | 20 | 190 | 80 | 4660 |
